LUMINOUS GRID TIE INVERTER NXI – 8KW, THREE PHASE
The Luminous NXI 8KW Three Phase Grid Tie Inverter is a robust, high-performance solution designed for commercial and industrial solar power systems. It efficiently converts solar energy into usable electricity, reduces dependency on grid power, and helps lower electricity bills by enabling export of surplus energy.
Key Features:
-
Rated Power Output: 8,000W (8KW)
-
Phase Type: Three Phase Output, suitable for commercial setups
-
High Conversion Efficiency: With a peak efficiency of up to 98%, it ensures optimal solar energy usage
-
MPPT Technology: Dual Maximum Power Point Trackers (MPPTs) provide smart tracking of panel voltage for increased energy harvest
-
Wide Operating Voltage Range: Ensures compatibility with various panel configurations
-
User-Friendly Interface: Integrated LCD display for real-time monitoring and status updates
-
Wi-Fi/GPRS Monitoring (optional): Remote performance tracking via mobile or web portal
-
Safe & Reliable:
-
Built-in protections for overvoltage, short circuit, overload, and reverse polarity
-
IP65 certified for outdoor installation – dustproof and water-resistant
-
-
Lightweight & Compact: Easy to mount and install on walls or other surfaces
-
Compliance: BIS certified and conforms to international safety and quality standards
Technical Specifications:
-
Rated AC Output Power: 8,000W
-
Max. DC Input Voltage: 1,000V
-
MPPT Operating Voltage Range: 200V – 800V
-
Number of MPPTs: 2
-
Max. Input Current per MPPT: 13A
-
Output Voltage Range (AC): 320V – 460V (3 Phase)
-
Frequency: 50/60Hz
-
Grid Type: On-Grid (No battery backup)
-
Cooling: Natural convection (fan-less design)
-
Dimensions (Approx.): Compact, wall-mountable design
-
Weight: Lightweight and manageable
Applications:
-
Commercial buildings
-
Educational institutions
-
Industrial facilities
-
Office complexes
-
Solar power plants
The Luminous NXI 8KW Grid Tie Inverter is the ideal solution for those looking to maximize solar energy utilization with a reliable, efficient, and low-maintenance system. Whether you’re managing a factory, a school, or a large office, this inverter delivers consistent performance and long-term savings.
Warranty: Product comes with a 10 years warranty.
